• High Energy Efficiency with models up to 10.0 EER saving you money when compared to other models
• Solid bottoms on outer-cases for full seal through the wall installation
• 100% Full Factory run test on all units for high reliability and dependability. Units start the first time, every time!
• Ball bearing fan motors that are reliable, start quickly and run quietly
• Multi-directional airflow to allow for cooling or heating to any part of the room. Some models contain automatic 2-way air swing feature
• Easy access slide out filter (left or right side pullout) has a permanent polypropylene filter mesh that is easy to remove and clean
• Hydrophilic coating on Evaporator and Condenser Coils on ALL models which allows better moisture removal, increased air flow, increased heat exchange, higher efficiencies and longer compressor life
• Condensate drain spouts on ALL models to direct condensate drainage
• LCDI power cords improve safety and protect against crimping or cuts on power cords

LITERATURE DOWNLOADS

FEATURES & BENEFITS

• There is a delay timer that can be set so that the unit will come on later and cool or heat to your desired set point. This is a single use timer, and will need to be set each day
• Electrical 6.0 LDCI power cord; Perpendicular plug; 20-amp circuit breaker
• Agency Approval U.L (Under Writers Laboratory) listed; USA and Canada
• Chassis Type: Slide-out for easy installation and service accessibility
• Fan Speeds: 2 speeds, High and Low
• Fan Only: Yes, High Speed
• Condensate Drain: Yes
• Condensate Drain Spout on the Wall Sleeve
• Window Kit: Yes
• High Energy Efficiency with models up to 10.0 EER saving you money when compared to other models
• Solid bottoms on outercases for full seal - thru the wall installation
• 100% Full Factory run test on all units for high reliability and dependability. Units start the first time - every time!
• Ball bearing fan motors that are reliable, start quickly and run quietly
• Multi-directional airflow to allow for cooling or heating to any part of the room. Some models contain automatic 2-way air swing feature
• Easy access slide out filter (left or right side pullout) has a permanent polypropylene filter mesh that is easy to remove and clean
• Hydrophilic coating on Evaporator and Condenser Coils on ALL models which allows better moisture removal, increased air flow, increased heat exchange, higher efficiencies and longer compressor life
• Condensate drain spouts on ALL models to direct condensate drainage
• LCDI power cords improve safety and protect against crimping or cuts on power cords

PRODUCT SPECIFICATIONS

• Cooling Capacity BTU: 9,000/8,700
• Cooling Current (Amps): 3.9/4.2
• Cooling Power (Watts): 910/880
• EER Rating: 9.9/9.9
• Moisture Removal (Pints/Hour): 2.20
• Heating Capacity BTU: 10,700/8,500
• Heating Current (Amps): 16.0/14.6
• Heating Power (Watts): 3,580/2,770
• Heat Pump Capacity BTU: 7,500/7,200
• Heat Pump Amps: 3.5/3.8
• Heat Pump Watts: 810/780
• COP: 2.8/2.8
• Air Flow CFM (H/M/L): 280

ELECTRICAL DATA

• Voltage: 230/208 Volt
• NEMA Plug Configuration: NEMA 6-20P, LCDI
• Power Cord Length: 4'

DIMENSIONS & WEIGHT

• Unit Width: 22 5/8"
• Unit Height: 15 3/8"
• Unit Depth: 24"
• Net Weight: 91 lbs.
• Shipping Weight: 111

LITERATURE DOWNLOADS

MANUFACTURERS WARRANTY

• 1-Year entire unit and 5-Year sealed system components. Goodman will repair or replace any factory defective part or sealed system leak caused by a defective part and pay labor and associated services costs directly related to the part replacement or repair. See product warranty for complete details.
