• High Energy Efficiency with models up to 10.0 EER saving you money when compared to other models.
• Solid bottoms on outer cases for full seal-thru the wall installation.
• 100% Full Factory run test on all units for high reliability and dependability. Units start the first time - every time!
• Ball bearing fan motors that are reliable, start quickly and run quietly.
• Multi-directional airflow to allow for cooling or heating to any part of the room. Some models contain automatic 2-way air swing feature.
• Easy access slide out filter (left or right side pullout) has a permanent polypropylene filter mesh that is easy to remove and clean.
• Hydrophilic coating on Evaporator and Condenser Coils on ALL models which allows better moisture removal, increased air flow, increased heat exchange, higher efficiencies and longer compressor life.
• Condensate drain spouts on ALL models to direct condensate drainage
• LCDI power cords improve safety and protect against crimping or cuts on power cords.

LITERATURE DOWNLOADS

FEATURES & BENEFITS

• There is a delay timer that can be set so that the unit will come on later and cool or heat to your desired set point. This is a single use timer, and will need to be set each day
• Electrical 6.0 LDCI power cord; Perpendicular plug; 20-amp circuit breaker
• Agency Approval U.L (Under Writers Laboratory) listed; USA and Canada
• Chassis Type: Slide-out for easy installation and service accessibility
• Fan Speeds: 2 speeds, High and Low
• Fan Only: Yes, High Speed
• Condensate Drain: Yes
• Condensate Drain Spout on the Wall Sleeve
• Window Kit: Yes
• High Energy Efficiency with models up to 10.0 EER saving you money when compared to other models
• Solid bottoms on outercases for full seal - thru the wall installation
• 100% Full Factory run test on all units for high reliability and dependability. Units start the first time - every time!
• Ball bearing fan motors that are reliable, start quickly and run quietly
• Multi-directional airflow to allow for cooling or heating to any part of the room. Some models contain automatic 2-way air swing feature
• Easy access slide out filter (left or right side pullout) has a permanent polypropylene filter mesh that is easy to remove and clean
• Hydrophilic coating on Evaporator and Condenser Coils on ALL models which allows better moisture removal, increased air flow, increased heat exchange, higher efficiencies and longer compressor life
• Condensate drain spouts on ALL models to direct condensate drainage
• LCDI power cords improve safety and protect against crimping or cuts on power cords

PRODUCT SPECIFICATIONS

• Cooling Capacity BTU: 17,600/17,200
• Cooling Current (Amps): 7.1/7.6
• Cooling Power (Watts): 1,630/1,1590
• EER Rating: 10.8/10.8
• Moisture Removal (Pints/Hour): 4.20
• Heating Capacity BTU: 11,000/9,000
• Heating Current (Amps): 16.0/15.6
• Heating Power (Watts): 3,680/3,030
• Heat Pump Capacity BTU: N/A
• Heat Pump Amps: N/A
• Heat Pump Watts: N/A
• COP: N/A
• Air Flow CFM (H/M/L): 450

ELECTRICAL DATA

• Voltage: 230/208 Volt
• NEMA Plug Configuration: NEMA 6-20P, LCDI
• Power Cord Length: 4'

DIMENSIONS & WEIGHT

• Unit Width: 26"
• Unit Height: 16 7/8"
• Unit Depth: 27 3/4"
• Net Weight: 132 lbs.
• Shipping Weight: 151

LITERATURE DOWNLOADS

MANUFACTURERS WARRANTY

• 1-Year entire unit and 5-Year sealed system components. Goodman will repair or replace any factory defective part or sealed system leak caused by a defective part and pay labor and associated services costs directly related to the part replacement or repair. See product warranty for complete details.
